آلة طباعة الشاشة العادية تنسيق كبير

380 V-220 V Power supply; 5-7 Bar compress air

Advantage

• The four-column structure, the platform inside and outside of the platform, the web version vertically up and down, the printing head left and right.
• The platform, the web version and the printing process adopt the independent drive source, the motion coordination, the speed is stable adjustable.
• PLC control system and man-machine interface.
• High strength alloy drawing aluminum printing girder.
• Variable frequency motor drives the printing tool holder, photoelectric eye control stroke, independent adjustment, intelligent quantitative control speed.
• The printing driven guide adopts the precision orientation of the straight square guide rail.
• Fluctuation motor drive screen and printing girder up and down, smooth movement.
• In Taiwan, the line guide rail of silver 50 is synchronized to the same direction.
• The overall fine grinding stainless steel platform runs in a straight line to the printing position and the upper material.
• The printing platform is operated by Taiwan intelligent numerical control reduction motor drive, linear square guide rail precision orientation, photoelectric eye precise control positioning.
• The upper material is on the outer end and runs to the other end for the printed area namely the inner end.
• The printing platform with fan, can choose long time adsorption and automatic suction mode.
• Printing platform level and vertical direction with precision fine tuning handle, fine tuning precision, color matching for easy edition.
• The operation interface has a variety of humanized printing modes, automatic printing indirect time digital control (1~9 seconds).
• The independent design of the head lifting device, scraper/return ink knife, net edition loading and unloading and screen cleaning are convenient.
• The control device of the right and left net clamping arm is easy to adjust. Pneumatic interlocking fixed screen device.
• The Angle of the scratch and the return ink can be adjusted, and the pneumatic automatic synchronizing off the net device.
• Printing scraper with anti-drop ink system to ensure more uniform printing color.
