آلة ختم الساخنة تصميم المهنية لأكياس التسوق

  • $12776
    ≥1
    Set/Sets
Payment Type:
L/C,T/T,Western Union
Incoterm:
FOB,CIF
Min. Order:
1 Set/Sets
Delivery Time:
7 Days
Transportation:
Ocean
Port:
Shenzhen,Guangzhou,Hongkong
  • وصف المنتج
Overview
Product Attributes

نموذجHH-TC4060LPT

علامة تجاريةكيه سي

Supply Ability & Additional Informations

تفاصيل التعبئة والتغليفحقيبة خشبية

إنتاجية100 Sets/month

نقلOcean

مكان المنشأدونغقوان

تفاصيل التجارة القدرة علي التوريد100 Sets/month

الشهاداتCE

ميناءShenzhen,Guangzhou,Hongkong

الدفع نوعL/C,T/T,Western Union

IncotermFOB,CIF

موعد التسليم7 أيام

التعبئة والتغليف والتسليم
بيع الوحدات:
Set/Sets
نوع الحزمة:
حقيبة خشبية

Hydraulic shopping bags embossing stamping machine //Usage and characters

Gild-49

  • Gilding - paper, leather, wood, plastic,
  • Baked - wood products, baked painting, gift box packaging;
  • Embossing - paper, leather, cloth.
  • Flat-object stamping machine with large-pressure, Suitable for stamping on invitation letter, card. Leather, wooden gift, Paper package, Plastics film, Electron products;
  • Manual. Automatic feed foil, automatic temperature controlling ensures stamping quality.
  • Because of large pressure, It is suitable for gilding and baking Impression on leather, paper, wooden materials.
  • Hydraulic drive, pressure more large.

Application fields

  • Paper Gilding, Leather Impression, Wood ware Baking
  • Paper Concave-convex embossing, Cloth hot stamping,
  • Plastics Bronzing
  • Mobile screen, Household appliances Panel , Thick paper card, PVC board Etc. large dimension Flat substrate stamping and Bronzing.
  • Woodiness objects baking-burns and Impress;
  • Leather bronzing and Molding;
  • Paper products concavo indentation.
  • Graduated disc of clock bronzing.
  • Die-cutting

Hydraulic embossing stamping Machine for shopping bag //Parameter

HH-TC4050LPTB


  • 1. Hot plate area:400 ×500 mm
  • 2. Working table area:520 ×800mm
  • 3. Max printing pressure:20,000 Kg
  • 4. Up and down distance:100mm
  • 5. Heat wattage: 6×500W
  • 6. Foil in feed: Motor Drive
  • 7. Temperature adjustment:0-300oC .


HH-TC4060LPTB


  • 1. Hot plate area:400 × 600 mm
  • 2. Working table area:520 ×800mm
  • 3. Max printing pressure:20,000 Kg
  • 4. Up and down distance:100mm
  • 5. Heat wattage: 6×500W
  • 6. Foil in feed: Motor Drive
  • 7. Temperature adjustment:0-300oC


Works supply :110V-220V Power supply ; 46# Hydraulic oil

Package list  Size: 1.16*1.2*1.9 m, 0.75*0.55*0.83 m

Gross weight: 780 kg; 85 kg;

CBM: 2.6448, 0.342375

H.S.Code: 8443198000

Certificate: CE

Hydraulic paper shopping bags embossing stamping machine //Advantage

  • Bench made ofhigh strength cast steel forging, has a very high flatness and stability;
  • Thread rising institutions to adjust the table lift to facilitate the opening and closing of space according to the height adjustment of the product tipping machine;
  • Relay control program is running, easy operation, easy maintenance;
  • Pairs of buttons control the stamping head up and down, security is greatly enhanced;
  • Hydraulic drive instead of the pneumatic drive, stamping pressure significantly improve the stability is greatly enhanced;
  • Heating pipe heating, rapid heating, replacement is simple and convenient;
  • Heating plate can be removed to facilitate installation and replacement gilt template;
  • Ironing board and table parallelism can be adjusted to facilitate the flexible adjustment depending on the size of the different regions of the pressure;
  • Automatic temperature control system can be set depending on the product temperature, automatic temperature control; temperature control accuracy of about 5 degrees;
  • Hot foil stamping degree of time and rolls of time can be set freely according to different technical requirements;
  • Foil paper automatic document feeder, conveyor length can be set according to the size of the stamping area of freedom.
